DEHNcube 2 YPV 1+2 1000 2M 2S FM
| Type of manufacturer: | DCU 2 YPV 1+2 1000 2M 2S FM |
|---|---|
| Manufacturer Art. No.: | 900976 |
| Art. Nr.: | 14010 |
| Pieces per package unit: |
|
| Accessory type: | Overvoltage protection |
Prices are only visible to business customers upon successful registration.
Available from stock
Product number:
14010
Description
DEHNcube 2 YPV 1+2 1000 2M 2S FM, GAK Type 1+2, IP65, 2 MPPT and 2 strings each at 1000 V DC
Do you want to protect your PV system effectively against overvoltage? The DEHNcube generator connection box reliably protects two MPP inputs, each with two strings, up to 1000 V DC. Thanks to integrated surge protection (Type 1+2) and push-in terminals, installation is quick and safe. Ideal for outdoor use with a robust housing (IP65) and clearly labelled cover.
Product benefits
- Protection of two MPP inputs, each with two strings
- Integrated Type 1 + Type 2 surge protection in accordance with EN 61643-31
- Push-in terminals for quick connection of inputs and outputs
- IP65 housing for long-lasting outdoor use
- Quick status check thanks to transparent cover with labelling
- Compact solution with efficient cable routing and high safety
Product features
- 2 MPP inputs, 2 strings each
- Max. PV voltage: 1000 V DC
- Lightning surge current (10/350 µs): 12.5 kA
- Rated discharge surge current (8/20 µs): 20 kA
- Protection level: ≤ 3.8 kV
- Rated load current: 30 A
- Response time: ≤ 25 ns
- Protection rating: IP65 for outdoor applications
- FM contact: Changeover, suitable for AC and DC
- DC connection cross-section: 2.5–6 mm² fine-stranded
