DEHNcube 2 YPV 1+2 1000 3M 2S FM

DEHNcube 2 YPV 1+2 1000 3M 2S FM – GAK Type 1+2 in an IP65 enclosure for PV systems with 3 MPPT units and 2 strings each at 1000 V DC

Do you want to reliably protect your PV system against overvoltage whilst efficiently connecting multiple strings? The DEHNcube DCU 2 YPV 1+2 1000 3M 2S FM is a pre-assembled generator connection box for up to three MPP inputs and two strings. With integrated Type 1+2 surge protection, push-in terminals, a transparent cover and IP65 protection rating, it offers you a robust complete solution for DC systems up to 1000 V.

Product benefits

• Protection for three MPP inputs with up to two strings
• Integrated Type 1+2 surge protection in accordance with EN 61643-31
• Push-in terminals for quick and secure connection
• Transparent cover with product labelling for easy maintenance
• Weatherproof housing with IP65 rating – ideal for outdoor use
• FM contact for remote monitoring of device status

Product features

• Max. PV voltage: 1000 V DC
• Protection class: IP65 (suitable for outdoor use)
• Discharge current (8/20 µs): max. 40 kA
• Lightning surge current (10/350 µs): 12.5 kA (total)
• Short-circuit withstand capacity: 10 kA
• Rated load current: 30 A
• Connection cross-section: up to 35 mm² (multi-strand), 25 mm² (fine-strand)
• FM contact connection: 1.5 mm² max.
• Dimensions: 3x 6-way screw terminals + 2x M20
• Weight: 3.06 kg
