DEHNcube 2 YPV 1+2 1200 2M 1S MC4

DEHNcube 2 YPV 1+2 1200 2M 1S MC4, GAK Type 1+2, IP65, 2 MPPT channels, each with 1 string up to 1200 V DC

The DEHNcube PV DCU 2 YPV 1+2 1200 2M 1S MC4 provides efficient surge protection for your PV system. The compact generator connection box combines Type 1 and Type 2 surge arresters in a single unit and protects two MPP inputs as well as one string. Ideal for indoor use and rated for up to 1200 V DC, it impresses with high surge current resistance, a robust IP65 housing with MC4 connectors and a particularly installation-friendly design.

Product benefits

• Combined Type 1 and Type 2 surge arrester for optimum lightning and surge protection
• Protection for two MPP trackers and one string with just one device
• Robust IP65 housing with transparent cover for indoor use
• Pre-assembled at the factory with original MC4 connectors for easy installation
• Pressure equalisation element prevents condensation
• Clear status indication via green/red function for fault diagnosis

Product features

• 2 MPP inputs, 1 string each
• Max. PV voltage: 1200 V DC
• Surge protection: Type 1 + Type 2 / Class I + II
• Surge current withstand: 12.5 kA (10/350 µs), max. discharge current: 40 kA (8/20 µs)
• Protection level: < 3.8 kV
• Rated load current: 40 A
• Response time: ≤ 25 ns
• Operating temperature: -35 °C to +60 °C
• Connection: 4x MC4 plugs/sockets + 2x M20
• Housing colour: grey, Weight: 2.76 kg
