DEHNcube 2 YPV 1100 1M 1S MC4 FM
| Type of manufacturer: | DCU 2 YPV 1100 1M 1S MC4 FM |
|---|---|
| Manufacturer Art. No.: | 900911 |
| Art. Nr.: | 14006 |
| Pieces per package unit: |
|
| Accessory type: | Overvoltage protection |
Prices are only visible to business customers upon successful registration.
Available from stock
Product number:
14006
Description
DEHNcube 2 YPV 1100 1M 1S MC4 FM, GAK Type 2 in an IP65 enclosure for 1MPPT PV systems with 1 string up to 1100 V DC
Do you want to equip your Photovoltaic system with a reliable DC protection system? The DEHNcube DCU 2 YPV 1100 1M 1S MC4 FM offers you optimum Type 2 surge protection for one MPP input and one PV string up to 1100 V DC. Thanks to its IP65 rating, original MC4 connectors and a transparent cover with labelling, it is perfectly suited for indoor use in modern PV systems.
Product benefits
- Protection for one MPP and one PV string up to 1100 V DC
- Integrated Type 2 surge protection (EN 61643-31)
- MC4 plugs and sockets for secure connection
- FM contact for remote monitoring
- IP65 – robust housing for demanding environments
- Transparent cover with labelling for quick identification
Product features
- Max. PV voltage: 1100 V DC
- Protection class: IP65
- Total surge current (8/20 µs): 40 kA
- Rated load current: 40 A
- Response time: ≤ 25 ns
- Protection level: ≤ 4 kV
- Temperature range: –35 °C to +60 °C
- Connection: Original MC4 plug/socket
- FM contact (changeover): 250 V AC / 0.5 A or 75 V DC / 0.5 A
- Housing with pressure equalisation element
