DEHNcube 2 YPV 1100 1M 2S
| Type of manufacturer: | DCU 2 YPV 1100 1M 2S |
|---|---|
| Manufacturer Art. No.: | 900913 |
| Art. Nr.: | 14023 |
| Pieces per package unit: |
|
| Accessory type: | Overvoltage protection |
Prices are only visible to business customers upon successful registration.
Available from stock
Product number:
14023
Description
DEHNcube 2 YPV 1100 1M 2S, GAK Type 2, IP65, 1 MPPT and 2 strings at 1100 V DC
The DEHNcube PV DCU 2 YPV 1100 1M 2S provides reliable protection for your PV system against overvoltages. The generator connection box is specially designed for systems up to 1100 V DC and provides protection for one MPP input and two strings. Thanks to integrated Type 2 surge arresters and push-in terminals, installation is quick and safe – ideal for outdoor use in demanding conditions.
Product benefits
- Effectively protects one MPP input and two strings
- Type 2 surge protection for high safety
- Push-in terminals for quick and safe wiring
- Robust housing with IP65 rating – ideal for outdoor use
- Transparent cover with status indicator for easy monitoring
- Suitable for PV systems up to 1100 V DC
Product features
- 1 MPP input, 2 strings
- Max. PV voltage: 1100 V DC
- Short-circuit withstand capacity: 10 kA
- Total discharge current: 40 kA
- Protection level: ≤ 4 kV
- Rated load current: 40 A
- Operating temperature: -35 °C to +60 °C
- Protection class: IP65
- Cable entries: 2x 3-way + 2x M20
- Installation location: Outdoor
