DEHNcube 2 YPV 1100 3M 1S MC4 FM
| Type of manufacturer: | DCU 2 YPV 1100 3M 1S MC4 FM |
|---|---|
| Manufacturer Art. No.: | 900931 |
| Art. Nr.: | 14022 |
| Pieces per package unit: |
|
| Accessory type: | Overvoltage protection |
Prices are only visible to business customers upon successful registration.
Available from stock
Product number:
14022
Description
DEHNcube 2 YPV 1100 3M 1S MC4 FM, GAK Type 2, IP65, 3 MPPT channels, each with 1 string up to 1100 V DC
The DEHNcube PV DCU 2 YPV 1100 3M 1S MC4 FM provides reliable protection for three MPP inputs and one string each in Photovoltaic systems up to 1100 V DC. This generator connection box combines Type 2 surge protection with practical MC4 connectors and a robust housing for outdoor use. Ideally suited for PV systems with up to three MPPTs under high loads – compact, safe and easy to install.
Product benefits
- Reliable protection for three MPP inputs and one string
- Surge protection in accordance with EN 61643-31 Type 2 / Class II
- Ideal for PV systems up to 1100 V DC
- Easy connection thanks to original MC4 connectors
- IP65 protection rating – perfect for outdoor use
- Transparent cover for quick status checks
Product features
- 3 MPPT inputs, 1 string each
- Max. PV voltage: 1100 V DC
- Surge current (Imax): 40 kA
- Rated load current: 40 A
- Protection level ≤ 4 kV
- Response time ≤ 25 ns
- Operational/fault indication: green / red
- Connection cross-section up to 25 mm² fine-stranded
- Protection class IP65, outdoor use
- Weight: 2.24 kg
