DEHNshield DSH ZP B2 LSG A TT 255
| Type of manufacturer: | DSH ZP B2 LSG A TT 255 |
|---|---|
| Manufacturer Art. No.: | 909131 |
| Art. Nr.: | 13957 |
| Pieces per package unit: |
|
| Accessory type: | Overvoltage protection |
Prices are only visible to business customers upon successful registration.
- New
- Project articles
On request
Product number:
13957
Description
DEHNshield DSH ZP B2 LSG A TT 255
With the DEHNshield ZP, you can install a high-performance combined arrester (Type 1+2+3) for TT and TN-S systems in your main distribution board. This easy-to-install solution, based on 40 mm busbars, provides reliable protection for overhead line feed-in and complies with current standards. With an integrated circuit breaker, a 230 V power supply for RfZ/APZ and intelligent connection accessories, you are ideally equipped for modern energy infrastructures.
Product benefits
- Combined arrester with spark gap technology for maximum lightning and surge protection
- Complies with DIN VDE 0100-534 – ideal for overhead line feed-in
- Tool-free installation on 40 mm busbar system
- Power supply for RfZ/APZ applications included
- With sealable protective cover and plug-in system for quick wiring
- Integrated circuit breaker (6 A, B-type)
Product features
- Combined arrester Type 1 + Type 2 + Type 3
- Rated voltage: 230/400 V AC
- Max. continuous voltage: 255 V
- Lightning surge current (Iimp): 30 kA (N-PE), 7.5 kA (L-N)
- Protection level: ≤ 1.5 kV (L-N/PE)
- Mounting on 40 mm busbar
- IP 30 protection rating (with cover)
- Operating temperature: -40 °C to +80 °C
- Operating indicator: green/red
