Enwitec NA protection 86.3 kVA, 125 A - TNS & TT
| Type of manufacturer: | NA4105-PV-86.3KVA-TNS_TT_1.0 |
|---|---|
| Manufacturer Art. No.: | 10018521 |
| Art. Nr.: | 11073 |
| Pieces per package unit: |
|
| Accessory type: | Grid and system protection |
Prices are only visible to business customers upon successful registration.
Available from stock
Product number:
11073
Description
Enwitec NA protection 86.3 kVA, 125 A – TNS & TT
Central low-voltage protection and coupling switch for PV systems up to 77.6 kW / 86.3 kVA in accordance with VDE-AR-N 4105:2018-11.
Product features:
- Max. apparent power of the generation system: 86.3 kVA
- Mains voltage: 3 x 230 / 400 V, 50 Hz
- Rated current: 125 A
- Mains configuration: TT or TN-S (all-pole isolation)
- FRT capability: Yes
- Protection class: IP54
- Dimensions: approx. 360 x 720 x 230 (mm) (W x H x D)
- Weight: 13.6 kg
