Marzari metal roofing sheet, Slate 380 type, stainless steel
| Manufacturer Art. No.: | MTP-Schf380-E |
|---|---|
| Art. Nr.: | 16736 |
| Pieces per package unit: |
|
| Product type: | Replacement tile |
Prices are only visible to business customers upon successful registration.
- New
Product number:
16736
Description
Fast, efficient and safe – metal roof panels from Marzari
Adjusting the roof covering during hook-mounted installation is one of the most labour-intensive and time-consuming steps for a PV installer. Bending and tapping take time and jeopardise the roof’s watertightness. Marzari metal roof panels are available in sizes that fit perfectly with many tile and slate formats. Installation is, by comparison, simpler, neater and quicker.
The ‘Schiefer 380’ stainless steel metal roof panel replaces the 250 x 380 mm slate tile at the fixing point. It is designed for fixing with M10 or M12 hanger bolts. No foam wedge is required for the ‘Schiefer’ type.
Product advantages
- Innovative design accommodates roof loads with flexibility
- No damage to the roof covering with Marzari metal roof panels
- Flat-edged on three sides to prevent water from seeping under the roofing by capillary action
- Made of metal for high-quality installation, durability and sustainability
- No bending or hammering required
Model: Marzari Type Slate 380, stainless steel
Do you need replacement panels for your next PV installation on a slate roof? Order the Marzari metal roof panel, Slate 380 type, directly here in the Memodo Shop.
Technical specifications
- Suitable for: Eternit Rombus
- Dimensions: 250 x 380 mm
- Material: V2A stainless steel (1.4301)
- Thickness: 0.70 mm
- Fixing: M10 / M12 stud bolt
- Weight: 0.6 kg per piece
- Packaging unit: 20 pieces
-
Matching accessories
-
Alumero easyBOLT stud bolt M12 x 300 mm with quick-fit plate- Type of manufacturer: 802404
- Art. Nr.: 519
{ "id": "09d3b7688e5a5279941616898a6f0cc7", "item_brand": "", "item_name": "Alumero easyBOLT stud bolt M12 x 300 mm with quick-fit plate", "item_id": "519", "currency": "EUR", "item_variant": "", "price": "on_request", "item_list_id": "product", "item_list_name": "product", "extra": { "minPurchase": "20", "shopware_id": "09d3b7688e5a5279941616898a6f0cc7" } } -
- New
- Example image
Marzari metal roofing sheet, slate-effect type 380, black-grey- Type of manufacturer: Mtp Schf380 sg
