meteocontrol blueLog MX – RS485/422 expansion module
| Manufacturer Art. No.: | 538202 |
|---|---|
| Art. Nr.: | 12552 |
| Pieces per package unit: |
|
| Energy management systems: | Accessories, Commercial |
| Mounting type: | DIN rail |
| WEEE-Number: |
|
Prices are only visible to business customers upon successful registration.
Available from stock
Product number:
12552
Description
Meteocontrol blueLog MX-Modul RS485/422
Purpose: This module extends the blue'Log X controller by two RS485/422 communication interfaces.
Product advantages:
- Integration of additional inverters, external meters or sensors into PV monitoring
- Automatic interface detection, whether RS485 or RS422
- High communication speed
- Simple installation on top-hat rail in the control cabinet
- Compact design saves space in the distribution board
Technical specifications:
- Power supply: internal to the system
- Power consumption: approx. 1 W (depending on configuration)
- Interfaces: 2x RS485/422 (autodetection, 1200-115200 baud)
- Operating temperature: -20 °C to 70 °C
- Storage/transport temperature: -20 °C to 85 °C
- Protection category: IP20
- LED display: 4 LEDs for status display
Expansion module for blue'Log XC und XM
-
