OBO Rising floor, for PLMR installation trunking
| Type of manufacturer: | PLMR LR 1220 A2 |
|---|---|
| Manufacturer Art. No.: | 7218202 |
| Art. Nr.: | 12349 |
| Accessory type: | Fire protection |
Prices are only visible to business customers upon successful registration.
On request
Product number:
12349
Description
OBO riser, for PLMR installation duct
The OBO PLMR LR 1220 A2 rising floor is a specially developed component for the PLMR installation duct, which is ideally suited for outdoor applications. This rising floor allows obstacles in outdoor areas to be overcome and creates a 45° angle. Manufactured from stainless steel, the component offers a durable and safe solution for the installation of fire protection ducts. The simple screw connection and the choice of durable materials make it a perfect addition for installations in accordance with the BMI’s EltAnlagen 2020 regulations.
Product benefits:
- Facilitates the overcoming of obstacles in outdoor areas
- Made from high-quality, stainless steel
- Suitable for creating a 45° angle
- Easy to install using screws
- Durable and weather-resistant
- Precisely fits the PLMR installation duct
Technical specifications:
- Material: Stainless steel, grade 1.4301
- Length: 171 mm
- Width: 260 mm
- Height: 158 mm
- Angle: 45°
- Weight: 89.3 kg per 100 pieces
- Surface: Bright
- Suitable for outdoor use
- Cover fixing: Screwed
- Effective cross-sectional area: 18,500 mm²
