SolarEdge optimizer S1000-1GM4MBT

SolarEdge

Manufacturer Art. No.:	S1000-1GM4MBT
Art. Nr.:	9495
Pieces per package unit:	10 per carton 420 per pallet
Inverter type:	Optimizer
AC power:	1 kW
Warranty:	25 years
Communication:	Powerline, Kabel: 0.1 m/(+) 4,7 m (-) 0.10 m
MPP voltage range:	12,5 - 105 Volt

Prices are only visible to business customers upon successful registration.

Unfortunately you are not authorised to place orders

To purchase the item you need a certification from the manufacturer.

The article is currently not available in your country.

Please contact your personal contact person to find out the price of the product. You can find your contact person's contact information in your customer account.

There was an error when determining the product availabilty

Product number: 9495

Prices are only visible to business customers upon successful registration.

Unfortunately you are not authorised to place orders

To purchase the item you need a certification from the manufacturer.

The article is currently not available in your country.

Please contact your personal contact person to find out the price of the product. You can find your contact person's contact information in your customer account.

There was an error when determining the product availabilty

Product number: 9495

Perfect for commercial installations! The SolarEdge Optimizer S1000-1GM4MBT for two PV modules.

The S1000 optimizer is designed for two modules, so for large PV systems the amount of optimizers needed is halved. The S optimizers come with "sense connect" technology for even more safety. It monitors temperatures in cables and connectors and alerts to abnormal behavior before arcing occurs. The S1000 allows modules with up to 500 W to be used.

Product advantages:

"Sense connect" technology
For up to two 500 W modules
Arc detection
Original MC4 connector

Product features:

Weight: 1106 g
Dimensions: 129 x 155 x 52 mm
Cable length: Input cable 1.0 m / Output cable (+) 4.7 m (-) 0.10 m
Short circuit current: 15 A
MPPT voltage: 12.5 - 105 Vdc
Maximum short circuit current (Isc) 15 Adc
Maximum power 1000 W (modules with a power tolerance of up to +5% are permissible)
