SolarEdge & SolarEdge optimiser S1500-1GM4MBWD short cable
| Manufacturer Art. No.: | S1500-1GM4MBWD |
|---|---|
| Art. Nr.: | 13861 |
| Pieces per package unit: |
|
| Inverter type: | Optimizer |
| Warranty: | 25 years |
| Communication: | Powerline, output cables 5.8m (+) and 0.1m (-), input cables 2 x 0.1m |
| MPP voltage range: | 12,5 - 125 Volt |
Prices are only visible to business customers upon successful registration.
Product number:
13861
-
-
{ "id": "b3e39800862a5c2780956998b6188916", "item_brand": "", "item_name": "SolarEdge SE90K MC4", "item_id": "6453", "currency": "EUR", "item_variant": "", "price": "on_request", "item_list_id": "product", "item_list_name": "product", "extra": { "minPurchase": "1", "shopware_id": "b3e39800862a5c2780956998b6188916" } } -
{ "id": "9ed56738c58a5cc091c6ea767352919a", "item_brand": "", "item_name": "SolarEdge SE100K MC4", "item_id": "6454", "currency": "EUR", "item_variant": "", "price": "on_request", "item_list_id": "product", "item_list_name": "product", "extra": { "minPurchase": "1", "shopware_id": "9ed56738c58a5cc091c6ea767352919a" } }
-
Description
Perfect for commercial installations! The SolarEdge S1500-1GM4MBWD optimiser for two PV modules.
The S1500 optimiser is designed for two modules, so the number of optimisers required for large PV systems is halved. The S-series optimisers feature ‘Sense Connect’ technology for even greater safety. It monitors temperatures in cables and connectors and issues a warning in the event of abnormal behaviour before an arc fault occurs. The S1500 allows the use of modules with a power rating of up to 750 W.
Product benefits:
- "Sense connect" technology
- for up to two 750 W modules
- Arc detection
- Original MC4 connectors
Product features:
- Weight: 1087 g
- Dimensions: 129 x 165 x 52 mm
- Cable length: Input cable 0.1 m / Output cable (+) 5.7 m (-) 0.10 m
- MPPT voltage: 12.5 – 105 Vdc
- Maximum short-circuit current (Isc) 20 Adc
- Maximum power 1500 W (modules with a power tolerance of up to +5% are permitted)
-
