DEHNshield DSH ZP B2 SG TNS 255
| Type of manufacturer: | DSH ZP B2 SG TNS 255 |
|---|---|
| Manufacturer Art. No.: | 909440 |
| Art. Nr.: | 13966 |
| Pieces per package unit: |
|
| Accessory type: | Overvoltage protection |
Prices are only visible to business customers upon successful registration.
Available from stock
Product number:
13966
Description
DEHNshield DSH ZP B2 SG TNS 255
With the DEHNshield ZP DSH ZP B2 SG TNS 255, you can effectively protect your electrical installation against surges. The Type 1+2+3 combination arrester is ideal for residential buildings without external lightning protection – even with overhead line supply. Thanks to its compact design, you can easily install it between two earth switches in a meter panel. It also reliably supplies protected voltage to additional applications such as RfZ and APZ.
Product benefits
- Type 1+2+3 protection function for comprehensive safety
- Tool-free installation on 40 mm busbar system
- Ideal for meter panels thanks to its slim 38 mm width
- Integrated 230 V power supply for RfZ / APZ
- Suitable for residential buildings without external lightning protection
- Matching accessories included in the scope of delivery
Product features
- SPD Type 1+2+3 in accordance with EN 61643-11
- Rated voltage: 230/400 V AC
- Lightning surge current (Iimp): 7.5 kA per path, 30 kA total
- Rated discharge surge current: 20/80 kA (L/N-PE)
- Protection level: ≤ 1.5 kV
- Operating temperature: -40 °C to +80 °C
- Overcurrent protection up to 160 A gG
- TOV withstand voltage: 440 V / 120 min (L-N), 1200 V / 200 ms (N-PE)
- Mounting type: Snap-on to busbar
- Protection class: IP 30 with cover
-
