DEHNshield DSH ZP B2 TNS 255
| Type of manufacturer: | DSH ZP B2 TNS 255 |
|---|---|
| Manufacturer Art. No.: | 909340 |
| Art. Nr.: | 13962 |
| Pieces per package unit: |
|
| Accessory type: | Overvoltage protection |
Prices are only visible to business customers upon successful registration.
Available from stock
Product number:
13962
Description
DEHNshield DSH ZP B2 TNS 255
Are you looking for a high-performance combination arrester that reliably protects your residential building against surges? The DEHNshield ZP DSH ZP B2 TNS 255 combines protection classes Type 1, Type 2 and Type 3 in a single device – ideal for TN-S systems with overhead line feed-in. Thanks to tool-free mounting on the 40 mm busbar system, you can install it quickly and securely directly in the meter panel.
Product benefits
- Combined Type 1+2+3 protection for comprehensive surge protection
- Tool-free mounting on 40 mm busbar system
- Compact design with a width of just 38 mm – fits directly into the meter panel
- Suitable for buildings without external lightning protection
- Integrated terminal protection through energy coordination
- Cover clip supplied in accordance with DIN VDE 0603-1 for every meter panel installation
Product features
- Rated voltage: 230/400 V AC (50/60 Hz)
- Max. continuous voltage: 255 V AC
- Lightning surge current (Itotal): 30 kA
- Rated discharge surge current (In): 20 / 80 kA
- Protection level [L/N-PE]: ≤ 1.5 kV
- Mounting: Snap-on to 40 mm busbar
- Protection class: IP 30 (with cover)
- Connection cross-section: 16–25 mm², fine-stranded or multi-stranded
- Operating temperature: -40 °C to +80 °C
-
