Mennekes AMTRON Professional Twincharge - TCX PnC 22

Manufacturer Art. No.:	151632402
Art. Nr.:	15642
Pieces per package unit:	1 per carton 9 per pallet
Power:	22 kilowatt
Number of charging points:	1
Access control:	RFID
AC phases:	3
Surplus charging:	Yes
Charging port:	Socket
Energy meter:	MID compliant meter
KfW (441) förderfähig:	Yes
BMVI förderfähig:	Yes
Electric charging system:	Commercial (semi-public), Public, Wallbox

Prices are only visible to business customers upon successful registration.

Available from 18.06.2026

Product number: 15642

Prices are only visible to business customers upon successful registration.

Available from 18.06.2026

Product number: 15642

Recommended accessories
- Mennekes AMTRON ÜSS Prof. TC

  Art. Nr.: 15645

  Mennekes

  Available from 27.05.2026

  { "id": "20f28f2c76b3567da3a57db755e54927", "item_brand": "", "item_name": "Mennekes AMTRON ÜSS Prof. TC", "item_id": "15645", "currency": "EUR", "item_variant": "", "price": "on_request", "item_list_id": "product", "item_list_name": "product", "extra": { "minPurchase": "1", "shopware_id": "20f28f2c76b3567da3a57db755e54927" } }
- reev Connect Compact AC license key

  Art. Nr.: 10131

  Reev

  Available from stock

  { "id": "d978b0037e965acba3344f2199dd375a", "item_brand": "", "item_name": "reev Connect Compact AC license key", "item_id": "10131", "currency": "EUR", "item_variant": "", "price": "on_request", "item_list_id": "product", "item_list_name": "product", "extra": { "minPurchase": "1", "shopware_id": "d978b0037e965acba3344f2199dd375a" } }
- reev Connect Pro AC license key

  Art. Nr.: 10135

  Reev

  Available from stock

  { "id": "ea1f539b678b5ba3b14a4a3f77fb442a", "item_brand": "", "item_name": "reev Connect Pro AC license key", "item_id": "10135", "currency": "EUR", "item_variant": "", "price": "on_request", "item_list_id": "product", "item_list_name": "product", "extra": { "minPurchase": "1", "shopware_id": "ea1f539b678b5ba3b14a4a3f77fb442a" } }

Mennekes AMTRON Professional Twincharge - TCX PnC 22

The intelligent Mennekes AMTRON® Twincharge dual wallbox for all customers who organise professional operations via a backend system, such as charging infrastructure operators in industry and commerce. The connection box design ensures easy installation and allows for pre-installation.
The integrated mobile modem enables a direct connection to the backend system for monitoring and billing.

Product benefits

High-quality and functional design
Compliant with metrology regulations in accordance with type examination certificate DE-24-M-PTB-0041
ISO 15118: Plug & charge
In accordance with DIN EN 61439
Integration into the home network via Wi-Fi/LAN
Optional: app control, time-controlled charging, grid-controlled charging, home energy management

Product features Mennekes Wallbox Amtron Professional TCX PnC 22

Maximum charging power: 22 kW (3-phase)
2x Type 2 charging sockets for Mode 3
4x LEDs for status indication
Connectivity: Compatible with OCPP 1.5 and OCPP 1.6, Modbus TCP, EEBus, LAN (RJ45)
Calibrated energy meter (MID certified)
Access: Backend (e.g. app) or RFID card
Protection class IP 54
Dimensions: 539 x 492 x 235 mm (HxWxD)
Weight: 14 kg

Contents

1x Mennekes Amtron Professional TCX PnC 22
2x User RFID cards
