BYD Battery Max Lite 90 kWh
| Type of manufacturer: | Lite 90 |
|---|---|
| Art. Nr.: | 13464 |
| Battery type: | LFP |
| Commercial storage type: | Modular without inverter |
| Communication: | CAN / RS485 / Modbus TCP |
| Installation location: | Outdoor |
| Usable capacity: | 90 kWh |
| Warranty: | 10 years |
| WEEE-Number: |
|
Prices are only visible to business customers upon successful registration.
- New
On request
Product number:
13464
-
-
{ "id": "76dbe98040f25adf8d7fbaf3b2942689", "item_brand": "", "item_name": "SMA Sunny Island X 30", "item_id": "13519", "currency": "EUR", "item_variant": "", "price": "on_request", "item_list_id": "product", "item_list_name": "product", "extra": { "minPurchase": "1", "shopware_id": "76dbe98040f25adf8d7fbaf3b2942689" } } -
{ "id": "1a3e7b25803c520abb583a1b65c80576", "item_brand": "", "item_name": "SMA Sunny Island X 50", "item_id": "13520", "currency": "EUR", "item_variant": "", "price": "on_request", "item_list_id": "product", "item_list_name": "product", "extra": { "minPurchase": "1", "shopware_id": "1a3e7b25803c520abb583a1b65c80576" } }
-
Description
BYD Battery Max Lite 90 kWh
BYD Battery Max Lite 90 kWh is the largest and most powerful variant in the product range. With the proven LFP cell technology, the battery solution from BYD ensures a safe and long-lasting energy supply. It is the perfect choice for companies and larger energy systems that require a reliable, scalable and high-performance solution.
Product advantages
- High capacity: 90 kWh for larger applications and systems.
- Fast charging: 1C charging and discharging speed.
- Safety: Uses cobalt-free LFP battery cells for maximum safety and longevity.
- Flexibility: Easily scalable for future expansions. From 30 kWh to 90 kWh per cabinet. In parallel connection with 32 units even up to 2.88 MWh.
- Long life span: 10 years of warranty.
Product features Max Lite 90 kWh
- Usable battery capacity: 90 kWh
- Number of battery modules: 12 modules of 7.5 kWh each
- Nominal voltage: 921 V
- Max. charge/discharge current: 100 A / 170 A (peak 3 s)
- Communication: CAN / RS485 (Modbus TCP)
- Operating temperature range: -20 °C to +50 °C
- Dimensions: 2205 x 920 x 1300 mm (H x W x D)
- Total weight: 1300 kg
- Protection category: IP55
- Warranty: 10 years
Scope of delivery
- 12 x BYD Battery-Max Lite Modules
- 1 x BYD Battery-Max Lite Cabinet
Maximize your energy efficiency with the BYD Battery Max Lite 90 kWh. Contact us for a customized solution or order directly!
