Fox ESS Stackable AIO 5.0 kW 3-phase
| Type of manufacturer: | HQ3-5.0 |
|---|---|
| Manufacturer Art. No.: | 30-141-5024E-B0 |
| Art. Nr.: | 15957 |
| Pieces per package unit: |
|
| Phases: | 3 |
| Inverter type: | Hybrid inverter |
| MPP-Tracker: | 3 |
| AC power: | 5 kW |
| Warranty: | 10 years |
| Communication: | WLAN, LAN, 4G, RS485, CAN |
| MPP voltage range: | 150-950 Volt |
| Backup power capable: | Full Backup |
Prices are only visible to business customers upon successful registration.
- New
Product number:
15957
Description
Fox ESS Stackable AIO, the all-in-one solution from Fox ESS
The Fox ESS Stackable AIO is a modern, integrated energy storage system for private homes. Thanks to its modular design, the system can be flexibly adapted to different requirements and installation scenarios. The combination of a high-performance hybrid Inverter and scalable Battery storage system enables the efficient use of solar energy. With its simple plug-and-play installation and comprehensive monitoring functions, the Stackable AIO is particularly user-friendly. At the same time, the system impresses with high safety standards and durable components.
Minimum configuration of 2 battery modules
Maximum configuration of 6 battery modules
Product benefits
- Modular, stackable all-in-one system for flexible expansion
- Three-phase hybrid/AC Inverter for maximum efficiency
- Simple plug-and-play installation, can be carried out by a single person
- Integrated system monitoring via app and web portal (FoxCloud V2.0)
- IP66 protection rating – ideal for indoor and outdoor use
- Flexible PV dimensioning thanks to 3 MPPT trackers
- Support for modern applications such as AI and VPP systems
- Remote monitoring and control in real time
- Integrated EPS output for emergency power supply
- Virtually uninterrupted switchover (< 10 ms)
- Full backup capability (depending on system configuration)
- Parallel connection of up to 10 units possible for higher backup capacity
Product features
- Power classes: 5 kW to 15 kW
- 3 MPPT trackers with up to 20 A per string
- PV voltage range: approx. 120 – 950 V
- Battery type: Lithium-ion (LFP)
- Battery voltage range: 80 – 500 V
- Max. efficiency: up to 97.9%
- AC mains connection: 3-phase (400/230 V)
- Protection class: IP66
- Communication: Wi-Fi, LAN, 4G, RS485, CAN
- Cooling: passive or active depending on model
- Operating temperature: -25 °C to +60 °C
