SMA Sunny Tripower Hybrid X 12
| Manufacturer Art. No.: | STPH12-60 |
|---|---|
| Art. Nr.: | 15854 |
| Pieces per package unit: |
|
| Phases: | 3 |
| MPP-Tracker: | 3 |
| AC power: | 12 kW |
| Warranty: | 10 years |
| Communication: | Ethernet, WLAN |
| MPP voltage range: | 240 - 850 Volt |
| DC input power: | 18.000 Watt |
| Backup power capable: | Full Backup |
Prices are only visible to business customers upon successful registration.
- New
Product number:
15854
-
-
{ "id": "85a3ab7aaaa257e8b2cf4d28893c010f", "item_brand": "", "item_name": "SMA Sunny Tripower Hybrid Backup Solution 3P Backup Box", "item_id": "15850", "currency": "EUR", "item_variant": "", "price": "on_request", "item_list_id": "product", "item_list_name": "product", "extra": { "minPurchase": "1", "shopware_id": "85a3ab7aaaa257e8b2cf4d28893c010f" } } -
{ "id": "0faad48876075273b167d615ad177ab2", "item_brand": "", "item_name": "SMA Sunny Tripower Hybrid Backup 3P DIN rail solution", "item_id": "15842", "currency": "EUR", "item_variant": "", "price": "on_request", "item_list_id": "product", "item_list_name": "product", "extra": { "minPurchase": "1", "shopware_id": "0faad48876075273b167d615ad177ab2" } } -
{ "id": "dff5489c22ca51f7a1b1ddc9b54f416e", "item_brand": "", "item_name": "SMA Sunny Tripower Hybrid Backup 4P Backup Box", "item_id": "15851", "currency": "EUR", "item_variant": "", "price": "on_request", "item_list_id": "product", "item_list_name": "product", "extra": { "minPurchase": "1", "shopware_id": "dff5489c22ca51f7a1b1ddc9b54f416e" } } -
{ "id": "856326df183b59a58849a3b45f5a8112", "item_brand": "", "item_name": "SMA Sunny Tripower Hybrid Backup 4P DIN rail solution", "item_id": "15852", "currency": "EUR", "item_variant": "", "price": "on_request", "item_list_id": "product", "item_list_name": "product", "extra": { "minPurchase": "1", "shopware_id": "856326df183b59a58849a3b45f5a8112" } }
-
Description
SMA Sunny Tripower Hybrid X – The three-phase hybrid Inverter for maximum self-consumption in the home
The Sunny Tripower Hybrid X from SMA is the new generation of three-phase hybrid Inverters for modern home energy supply. With a power range from 5 kW to 15 kW, three independent MPP trackers and integrated cloud-based energy management, it offers maximum flexibility for a wide variety of system configurations – from a simple PV system to a fully self-sufficient energy system with a Battery storage system and backup power supply.
Product benefits of the SMA Sunny Tripower Hybrid X:
- Three-phase hybrid Inverter with 3 independent MPP trackers – ideal even for complex roof structures or shading
- Low minimum input voltage of 90 V allows the use of short strings
- Up to 37 kWh storage capacity when combined with SMA Home Storage or SMA Storage M
- Integrated cloud-based energy management (SMA Energy Maximizer) with self-learning algorithms and optimisation based on Dynamic electricity tariffs
- Optional backup power supply (SMA Backup) for the entire building – switchover time of just 1 second
- Parallel operation of up to 5 units for scalable system concepts
- Quick commissioning in just 5 minutes via the SMA 360° app
- 10-year manufacturer’s warranty upon registration at my.sma-service.com
- Cybersecurity architecture in accordance with ISO 27001 – developed and operated by SMA
Product features of the SMA Sunny Tripower Hybrid X:
- Rated AC power: 12,000 W
- Max. DC input power: 7,500 Wp to 22,500 Wp (DC/AC ratio 1.5)
- Number of MPP trackers: 3 (1 string each)
- MPP voltage range: 90 V to 850 V
- Battery voltage range: 80 V to 600 V
- Max. battery charge/discharge current: 50 A
- Max. efficiency: 98.3%
- Compatible batteries: SMA Home Storage, SMA Storage M, BYD Battery-Box HVB / HVS+ / HVM+
- Interfaces: Ethernet (2×), Wi-Fi, BAT-CAN, SMA Modbus, SunSpec Modbus
- Protection rating: IP65 (outdoor)
- Dimensions: 467 × 555 × 239 mm
- Weight: max. 33.5 kg
- Operating temperature range: −25 °C to +60 °C
-
