Raycap surge protection DC type I+II 2 MPPT, MC4
| Type of manufacturer: | ProTec T1-1100PV-5Y-2MC-BOX |
|---|---|
| Manufacturer Art. No.: | IZ515658000 |
| Art. Nr.: | 15785 |
| Accessory type: | Overvoltage protection |
Prices are only visible to business customers upon successful registration.
- New
Available from 13.07.2026
Product number:
15785
Description
Raycap DC surge protection, Type I+II for 2 MPPT
The Raycap ProTec T1-1100PV-5Y-2MC-BOX is a pre-assembled surge protection box designed to provide reliable protection for Photovoltaic systems on the DC side. This compact solution combines a high-performance Type 1+2 lightning and surge arrester in a robust housing and is ideal for PV systems with up to two MPP trackers. Thanks to the integrated MC4 connectors, installation is quick and straightforward.
The protection box has been developed for use in buildings with and without external lightning protection systems and meets the requirements of the IEC/EN 61643-31 standards. The durable housing with a high protection rating allows for use both indoors and outdoors.
Product features:
- Maximum continuous voltage: 1100 V
- Total lightning surge current: 12.5 kA
- Rated current: 35 A
- Protection class: IP 67
- Number of MPP trackers: 2
- PE conductor cross-section: up to 16 mm²
- PV string connection with MC4 connectors (Stäubli)
- Mounting type: Wall - Indoor/Outdoor
